Home /Products/Tesla EV Car Parts/Tesla Model 3 2023+ Front Right Door Latch 1738945-01-D

Tesla Model 3 2023+ Front Right Door Latch 1738945-01-D

1
MOQ
Negotible
Price
Tesla Model 3 2023+ Front Right Door Latch 1738945-01-D
Features Gallery Product Description Request A Quote
Features
Specifications
Durability: High
Compatibility: Universal
Color: Black
Design: Sleek
Material: Composite Materials
Highlight:

Tesla Model 3 door latch

,

right hand door latch

,

2023 Tesla Model 3 latch
Basic Infomation
Place of Origin: China
Brand Name: CFN
Model Number: 1738945-01-D
Payment & Shipping Terms
Packaging Details: 170*80*35 one piece,Box
Delivery Time: 5-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100
Product Description
Front Right-Hand (RH) Door Latch for 2023+ Tesla Model 3 | 1738945-01-D (CFN Brand)​
This front right-hand (RH) door latch (part number 1738945-01-D) is an OEM-matching electro-mechanical component for 2023+ Tesla Model 3 (all variants). It integrates into the front right door’s inner frame, working with the 2023+ Model 3’s updated door hardware (electronic exterior handle, central locking module) to control door operation, aligning with Tesla’s latest safety logic.​
Core Functions​
  1. Secure Locking/Unlocking: Syncs with the BCM to execute commands from key fob, touchscreen, or exterior handle. When locked, it engages the stainless steel striker to prevent accidental opening; when unlocked, it releases smoothly for easy access.​
  1. Reliable Operation: Features a high-torque solenoid (responds in ≤0.3s) and mechanical linkage. The interior handle has a backup mechanical system for electrical failures. It also has a “half-latch” function—catching the striker if the door isn’t closed and triggering a dashboard alert.​
  1. Safety Protection: Auto-locks during collisions to avoid occupant ejection; has a hidden manual pull tab for emergencies. Coordinates with the anti-pinch sensor to reverse closing if resistance is detected.​
Durable Construction​
  • Mechanical Part: Main body uses glass-fiber reinforced PA66 (tensile strength ≥85MPa); moving parts (pawl, ratchet) are hardened steel (HRC ≥52), supporting 60,000+ opening cycles.​
  • Electronics: Solenoid with copper coils (insulation class B, 130°C resistance); Hall-effect sensor (accuracy ≤0.8%) for real-time status feedback.​
  • Sealing: IP6K7 gaskets and waterproof connectors block water/dust; tolerates -40°C to 90°C, resisting salt corrosion.​
Installation​
  1. Power off, disconnect 12V battery, remove front right inner door panel (detach clips, disconnect wiring/cables).​
  1. Remove old latch: disconnect connector/cables, take out 3×10mm bolts, and pull it away.​
  1. Clean the mounting surface, check the striker (tighten or replace if needed).​
  1. Align 1738945-01-D, reconnect connector/cables, hand-tighten bolts, then torque to 8±0.5 Nm.​
  1. Reconnect battery, reinstall panel, test locking/unlocking, anti-pinch, and clear BCM codes.​
Note: Front RH-specific—do not interchange with other latches (e.g., 1738944-01-D).
